Product: 45A 12V/24V/48V MPPT Charge Controller – Felicity Solar SCCM4548 Type: MPPT Solar Charge Controller Maximum Charging Current:45A Battery Voltage:12V / 24V / 48V DC Maximum PV Input Voltage:145V DC Maximum PV Input Power:12V – 625W / 24V – 1250W / 48V – 2500W Efficiency: Up to 98% Application: Residential, commercial, off-grid, and hybrid solar power systems. Features: Advanced MPPT technology, automatic battery voltage detection, intelligent three-stage charging, MODBUS communication support, support for lithium and lead-acid batteries, comprehensive electronic protection, and efficient solar energy management.
45A 12V/24V/48V MPPT Charge Controller – Felicity Solar SCCM4548
Product Overview
The Felicity Solar SCCM4548 is a reliable 45A MPPT Solar Charge Controller designed to maximize the performance of off-grid and hybrid solar systems. Using advanced Maximum Power Point Tracking (MPPT) technology, it extracts more energy from solar panels, increasing charging efficiency by up to 25–30% compared to conventional PWM controllers while delivering a maximum conversion efficiency of 98%.
Compatible with 12V, 24V, and 48V battery systems, the SCCM4548 automatically detects battery voltage (except lithium batteries, which require manual configuration). It supports lithium, AGM, GEL, and flooded lead-acid batteries, making it suitable for residential, commercial, agricultural, and backup solar applications.
System Design & Configuration
45A MPPT Charging
Delivers up to 45A charging current for small to medium-sized solar power systems.
Advanced MPPT Technology
Tracks the maximum power point continuously to maximize solar energy production.
12V / 24V / 48V Compatibility
Automatically detects system voltage for lead-acid batteries and supports manual lithium battery configuration.
Three-Stage Intelligent Charging
Bulk, Absorption, and Float charging optimize battery performance and extend battery lifespan.
Wide Battery Compatibility
Supports Lithium, AGM, GEL, and Flooded Lead-Acid batteries.
Comprehensive Protection
Built-in safety features protect against overvoltage, reverse polarity, overheating, overload, and short circuits.
Technical Specifications
Specification
Details
Model
SCCM4548
Brand
Felicity Solar
Controller Type
MPPT Solar Charge Controller
Maximum Charging Current
45A
Battery Voltage
12V / 24V / 48V DC
Maximum PV Input Voltage
145V DC
PV Start-Up Voltage
15V DC
Maximum PV Input Power
12V – 625W / 24V – 1250W / 48V – 2500W
Maximum Efficiency
Up to 98%
Charging Algorithm
3-Stage (Bulk, Absorption, Float)
Communication
Intelligent Slot (MODBUS Compatible)
Battery Types
Lithium, AGM, GEL, Flooded Lead-Acid
Protection Rating
IP20 (Indoor Installation)
Specifications are based on the manufacturer’s published data.
Key Features
45A maximum charging current 12V, 24V & 48V battery compatibility Advanced MPPT technology Up to 98% conversion efficiency Automatic battery voltage detection Supports lithium and lead-acid batteries Three-stage intelligent charging MODBUS communication support Comprehensive electronic protection LCD system monitoring Reliable long-term performance Energy-efficient charging
Applications
Residential solar systems Commercial solar installations Off-grid solar systems Hybrid solar systems Battery backup systems Agricultural solar projects Telecommunication systems Remote power installations
Installation & Usage Guidelines
Install indoors in a dry and well-ventilated area.
Connect the battery before connecting the solar panels.
Use properly rated DC cables and protection devices.
Configure the correct battery type before use.
Ensure adequate airflow around the controller.
Monitor charging status regularly.
Maintenance & Care
Keep the controller clean and dust-free.
Inspect cable connections periodically.
Tighten loose electrical terminals.
Ensure ventilation openings remain unobstructed.
Check battery settings during maintenance.
Perform routine inspections for optimal performance.
Best Practices
Recommended
Use high-quality solar panels and batteries.
Configure the correct charging profile.
Install suitable DC breakers and fuses.
Monitor charging performance regularly.
Follow recommended wiring practices.
Avoid
Exceeding the maximum PV input voltage.
Installing in damp or poorly ventilated environments.
Connecting batteries with reversed polarity.
Blocking ventilation openings.
Ignoring system warning indicators.
Performance Overview
Function
Performance
Charging Efficiency
Excellent
MPPT Tracking
Excellent
Battery Protection
Excellent
System Reliability
Excellent
Energy Harvest
Excellent
Frequently Asked Questions
What battery voltages does the SCCM4548 support?
It supports 12V, 24V, and 48V battery systems with automatic voltage detection for lead-acid batteries. Lithium batteries require manual configuration.
What is the maximum charging current?
The controller provides a maximum battery charging current of 45A.
What is the maximum PV input voltage?
It supports a maximum solar input voltage of 145V DC.
Does it support lithium batteries?
Yes. The SCCM4548 supports lithium batteries as well as AGM, GEL, and flooded lead-acid batteries.
What charging method does it use?
It uses a three-stage charging algorithm (Bulk, Absorption, and Float) to maximize battery performance and lifespan.
Why Choose the Felicity SCCM4548 MPPT Charge Controller
45A high-capacity charging Advanced MPPT technology Up to 98% efficiency 12V, 24V & 48V compatibility Supports multiple battery chemistries Intelligent three-stage charging Reliable electronic protection Ideal for residential and commercial solar systems
